Cone Winding Machine Demystified: Your Ultimate Reference



What is a cone winding machine?

Cone winding is the first process of preparation before weaving, its task is to process the pipe yarn or hank yarn from the spinning department into certain requirements on the winding machine. As the last process of spinning and the first process of weaving, winding plays the role of “bridge”, so it plays an important role in the field of textile.

The speed of cone winding machine

The speed of cone winding machine should be determined according to the quality of yarn, the better the quality of yarn is, the less the deterioration of the tube yarn will be, on the contrary, the deterioration will increase; At the same time, the winding speed is closely related to the unwinding tension of the yarn, and the unwinding tension at low speed is smaller than that at high speed. In the whole unwinding process, large and medium yarn tension is relatively small, less unwinding, winding speed can be slightly higher, but when unwinding to the small yarn part, unwinding tension double, easy to produce unwinding, which also restricts the improvement of winding speed, so in the large and medium yarn should improve the speed, small yarn should be properly reduced speed, so that the actual speed of winding.
​
According to experience, when spinning medium and fine size varieties, we generally choose +30% as the starting speed change percentage of VSS system, 60% as the final speed change percentage, 70% as the change percentage. It can be seen that when spinning different number varieties, the speed and tension change with the change of number. The lower the number, the lower the speed and tension. This is because the yarn strength of fine gauge yarn is smaller than that of thick gauge yarn. If high speed unwinding is adopted, long detail yarn defects are easy to occur, which will deteriorate yarn quality and lead to deterioration of CV value, hairiness, strength and other indexes. In serious cases, there will be accidental breakage, resulting in the increase of yarn, and then affect the production efficiency of enterprises.
​
The choice of yarn winding speed also takes into account other factors, such as supply issues and the more important yarn index deterioration. Under normal circumstances, it is appropriate to keep the deterioration degree of CV value within 0.5%, and the -30% details of yarn should not exceed 200 /km, and this value will increase with the decrease of yarn size.

The objective of cone winding machine

Change the packing to increase the amount of yarn in the packing:
A larger bobbin is made by connecting smaller volumes of yarn (or hank) through a winding tube, with one bobbin holding the equivalent of more than 20 yarns. Bobbin can be used for warping, twisting, winding, dyeing, weft on shuttleless looms and knitting yarns. If the pipe yarn is directly used in these processes, the downtime will be too much, which will affect the improvement of production efficiency and product quality. Therefore, increasing the coiling capacity is a necessary condition to improve the productivity and quality of the latter process.
Remove the yarn defects and improve yarn quality:
There are defects and impurities in the yarns produced by cotton mills, such as thick knots, details, double yarns, weak twist yarns, knots and so on. The yarn cleaning device is used to check the yarn during winding, remove the defects and impurities affecting the quality of the fabric, improve the uniformity and finish of the yarn, so as to reduce the broken end of the yarn in the latter process and improve the appearance quality of the fabric. It makes the most sense for yarn defects and impurities to be removed during the winding process, as each bobbin works independently, allowing the others to continue working undisturbed while one bobbin deals with a broken end.
